Active Vibration Isolation System TS series (Desktop type)

Today's demanding applications require isolation in the low frequency range at 5 Hz and below.

The TS series is an advanced, fully-automatic vibration control system with turn-key installation.

Active isolation in six degrees of freedom, from 0.7 Hz to 100 Hz.
The TS features automatic height load adjustment which maintains height and level with an instrument loaded on top.

TS-150

The TS series offers great performance in a compact, lightweight package. It is an extremely high value-added vibration control system.

In the nano technology of 21st Century (i.e. advanced semiconductor representing the information related technology, life science related technologies such as gene therapy, atomic or molecular processing such as MEMS and engineering technology such as new material production), vibrations, noise, electro- magnetic fields, heat, humidity, disturbance and etc. will be inhibiting factors of the measuring environment.
In nano technology, to obtain a reliable result, an active-isolation is required in the low frequency range which are difficult to isolate with air tables.
The advanced active vibration isolation system "TS series" will support as the vibration isolation technology basis of the nano technology in the 21st century. It will contribute to the development of the present technology and measurement, creation and development of the unknown technology.

Features

Compact

The TS??series is a low profile isolation system. It offers cutting edge performance in a compact package. Depending on your application, it can be used on the tabletop or can be integrated into your existing setup. It can support loads up to 230 kg.

Lightweight

The TS series is lightweight, starting at only 18 kg.This makes it extremely easy to move and place whereever you need it.

The Easy to Use

• The TS series provides auto leveling upon the instrument being loaded or moved. So it will maintain stability even when the load is off center.
• When an instrument's center of gravity is high, passive air isolation systems often struggle to achieve balance. However, the TS uses a coil spring so it can easily and quickly compensate for high center of gravity loads.
• The TS series offers an automatic??locking function to protect the system while being moved or transported. This feature can be activated with the push of a button.
• The front display shows actual vibration levels in X, Y, and Z directions. This provides feedback on vibration levels and diagnostic information on performance of the isolation. You can also monitor the accelerometer signals by connecting an oscilloscope to the BNC connector on the back of the system.
• The TS series is also available with a remote control box that enables/disables the active isolation.
  (Sold separately)

High Performance

TS series actively isolates from 0.7Hz to 100Hz in all six degrees of freedom.

Example of Vibration Isolation performance of TS Series...

The image of the hen chook albumen lysozyme with the atomic force microscope.

These are images by AFM with TS-150.
Left:20x20??m2 / Right:8x8??m2

Images provided by Mr.Takatomo Sasaki and Mr.Seizo Morita.

Comparison between passive and active isolation

Left:Imaging with Passive Isolation / Right:Imaging with Active Isolation

These images were taken with a Zygo NewView 5000 3D surface profiler??when loaded on a TS-300.
The first image shows imaging ??with the active isolation is off (passive isolation only). Diagonal ridges, caused by vibrations, are clearly visible. (Upper left image)
The second image was taken with the active isolation turned on. The image is not affected by vibrations at all. (Upper right image)

Images provided by Canon Marketing Japan

Mounting Plates with Drilled and Tapped Holes

The picture on left shows TS-150/LP with M6-25 mm XY matrix drilled and tapped holes mounting plate. This mounting plate is made of bonded ferromagnetic stainless steel and aluminum. It is available for all three models. A customized drill hole positions are also available upon request. However, a specific tap size may not be available. For a specific surface precision, please contact us.

Specifications

Model	TS-140	TS-150	TS-300LT	TS-300
Format	TS-140/TP25	TS-150/TP25	TS-300LT/TP25	TS-300/TP25
System configuration	Fully integrated system
Active control range	About 0.7Hz - 100Hz (Passive isolation beyond 100 Hz)
Adjustment for environment	Automatic gain and of fset adjustment
Load adjustment	Automatic load adjustment feature
Locking Mechanism	Automatic Lock Dow n feature for use in transporting the system
Vibration level monitoring	Real-time vibration levels are displayed on the f ront display.
Mounting plate size	500 *600mm	400 *450mm	600 *800mm
Overall dimensions (Approx.)	500 *600 *84Hmm	400 *450 *78Hmm	600 *800 *121Hmm
Load Capacity	100kg	100kg	90kg	230kg
System weight	About29kg	About18kg	About55kg	About60kg
Electric supply source/voltage	100-230VAC6¡Þ10%50-60Hz
Power consumption	Normal10W,50W maximum(70VA)
Operating temperature limits	5 deg C ~ 40 deg C
Operating humidity limits	10 ~ 90%(5 ~ 30¡ëC) 10 ~ 60%(30 ~ 40¡ëC)
Indoor / Outdoor Use	Indoors only
Operating altitude limit	Less than 2,000m
*TP25 mounting plate material	The surface of the mounting plate is paramagnetic stainless steel SUS430.
Unpainted brushed steel finishing	The machined mounting plate w ith M6/25XYmm matrix. Ef fective depth of the tap is 6mm
Accessory (2)	Remote on/of f sw itch.
Accessory (3)	Ultra rigid support f rame w ith built-in damping (Extra charge for custom sizes)
